Unity Solar System Simulation

Overview

Unity Solar System Simulation is a real-time, mathematically accurate 3D simulation of our planetary system built using Unity 6 and C# scripting. The project focuses on rendering orbital mechanics, planetary bodies, and realistic lighting models leveraging Unity's Universal Render Pipeline (URP) and custom shaders.

"Simulating gravity and orbital paths in real-time showcases the beautiful intersection between astrophysics, mathematics, and high-performance Unity engine programming."

Key Features

Technical Implementation

To model planet orbits, we solve Kepler's Equation at each frame step. Since Kepler's Equation has no analytical solution, we use Newton-Raphson iteration. The planetary parameters (semi-major axis, eccentricity, inclination, longitude of ascending node, argument of perihelion) are configured based on NASA's planetary data sheets.

Keplerian Orbit Position Solver (C#)

Here is a sample code snippet from the simulation logic showing how the 3D position is calculated in the orbital plane and then rotated into the ecliptic coordinate system:

using UnityEngine;

public class PlanetOrbit : MonoBehaviour
{
    [Header("Orbital Parameters")]
    public float semiMajorAxis = 10f;
    public float eccentricity = 0.0167f;
    public float orbitalPeriod = 365.25f;
    public float inclination = 0.0f;
    public float longAscNode = 0.0f;
    public float argPerihelion = 0.0f;

    private float meanAnomaly = 0.0f;

    void Update()
    {
        // Update Mean Anomaly based on time step
        float meanMotion = (2.0f * Mathf.PI) / orbitalPeriod;
        meanAnomaly += meanMotion * Time.deltaTime;
        meanAnomaly %= (2.0f * Mathf.PI);

        // Solve Kepler's Equation: E - e * sin(E) = M
        float E = SolveKepler(meanAnomaly, eccentricity);

        // Calculate coordinates in the orbital plane
        float x_orbital = semiMajorAxis * (Mathf.Cos(E) - eccentricity);
        float y_orbital = semiMajorAxis * Mathf.Sqrt(1.0f - eccentricity * eccentricity) * Mathf.Sin(E);

        // Convert to Radians
        float i_rad = inclination * Mathf.Deg2Rad;
        float Omega_rad = longAscNode * Mathf.Deg2Rad;
        float w_rad = argPerihelion * Mathf.Deg2Rad;

        // Rotate position to 3D ecliptic coordinates
        float cosO = Mathf.Cos(Omega_rad), sinO = Mathf.Sin(Omega_rad);
        float cosw = Mathf.Cos(w_rad), sinw = Mathf.Sin(w_rad);
        float cosi = Mathf.Cos(i_rad), sini = Mathf.Sin(i_rad);

        float x_ecl = x_orbital * (cosw * cosO - sinw * sinO * cosi) - y_orbital * (sinw * cosO + cosw * sinO * cosi);
        float y_ecl = x_orbital * (cosw * sinO + sinw * cosO * cosi) - y_orbital * (sinw * sinO - cosw * cosO * cosi);
        float z_ecl = x_orbital * (sinw * sini) + y_orbital * (cosw * sini);

        transform.localPosition = new Vector3(x_ecl, z_ecl, y_ecl); // Mapping Unity's coordinate system (Y-up)
    }

    private float SolveKepler(float M, float e)
    {
        float E = M;
        for (int step = 0; step < 5; ++step)
        {
            E = E - (E - e * Mathf.Sin(E) - M) / (1.0f - e * Mathf.Cos(E));
        }
        return E;
    }
}

Installation & Usage

Running the simulation locally requires Unity Hub and Unity Editor version 6 (6000.0+).

• Clone the repository from GitHub: git clone https://github.com/mskreallabs/Unity-Solar-System-Simulation.git.
• Open Unity Hub, click Add, and select the cloned project directory.
• Ensure Unity 6 is selected as the editor version and launch the project.
• In the project browser, navigate to Assets/Scenes/MainScene.unity and open it.
• Press the Play button in the editor toolbar to run and test the simulation interface.
